VX-241 PMR

Compact, Easy-to-Use Portable Communications
The VX-241 PMR446 radio is a 16-channel economical licence free radio providing long-lasting performance and reliability. The radio’s small size is easy to carry and it supports the fundamental two-way radio functions needed without added cost.

Built To Perform
Rated IP 54 for dust and water protection and tested to Military Standards for durability, the VX-241 is designed to provide years of reliable use.

Quality Audio Output
Designed with 500 mW audio output makes the VX-241 ideal for noisy environments.

Minimise Channel Interference
Choose from 1 of 50 CTCSS tones or 1 of 104 DCS sequences on each of the 8 pre-programmed PMR446 frequencies, which can then be allocated to any of the 16 channel locations.

Monitor Communication Status: Auto-Range Transpond System – ARTS™
Only Vertex Standard radios are designed to inform you when you and another ARTS™-equipped radio are within communication range. If out of range for more than 2 minutes, your radio senses no signal has been received and beeps to alert you. A great solution to keep everyone coordinated and exclusively offered in Vertex Standard radios.

Additional Features
• 16 channels
• Two programmable keys
• Fixed antenna
• Battery power save
• Low battery alert
• CTCSS / DCS Encode and Decode
• Scan
• Follow-me scan
• Time out timer (TOT)
• Manual squelch adjustment

• Busy channel lockout (BCLO)

General Specification

Frequency Range

8 pre-programmed PMR446 frequencies 446.00625 MHz – 446.09375 MHz

TX Output Power

500 mW ERP

Battery Life (5-5-90 duty) FNB-V103LIA

Up to 19 hours w/saver

Audio Output

500 mW @ 4 Ohms 5% THD

TX Output Power

500 mW ERP

IP Rating

IP 54

Operating Temperature Range

-25º C to +55º C

Dimension (H x W x D)

110 x 58 x 30 mm

Weight

270 g (w/FNB-V103LIA)

Power Supply Voltage

7.4 V DC +/-20%

Channel Spacing

12.5 kHz/p>

PLL Steps

6.25 kHz

Frequency Stability

±2.5 ppm

Sensitivity 20 dB SINAD

26.5 dBμV emf

Adjacent Channel Selectivity

55 dB

Intermodulation

60 dB

Spurious and Image Rejection

65 dB

Modulation

11K0F3E

Modulation Limiting

±2.5 kHz @ 12.5 kHz/p>

Spurious Emissions

-36 dBm ≤ 1 GHz, -30 dBm > 1 GHz

FM Hum and Noise

40 dB 12.5 kHz

Audio Distortion

< 3 % @1 kHz

• MH-450S: Speaker microphone

• MH-360S: Compact speaker microphone
• MH-45B4B: Noise cancelling speaker microphone
• MH-37A4B: Earpiece microphone
• VC-25: Over-the-head VOX headset
• FNB-V103LIA: 1380 mAh Li-Ion battery*
• VAC-300: Desktop rapid charger (CD-34 and PA-42)*
• DCM-1: Desktop charger bracket
• VCM-2: Vehicle charger mounting adapter
• VAC-6300: 6-Unit multi rapid charger
• LCC-351: Leather case
• LCC-351S: Leather case w/swivel belt clip
• CLIP-18: Belt clip*

*Included with radio
